FrontView surveys the space. You design from your desk.

Skip the tape measure and the camera roll. A FrontView technician scans the site with a professional-grade LiDAR scanner at its highest resolution, and you get measured existing conditions, a floor plan you can open in CAD, and a 3D space to show clients what's there and what could be.

A technician scanning an empty office floor with a handheld LiDAR scanner
What you get

Existing conditions, without the second site visit.

An office floor plan from above: open desks, meeting rooms, a lounge and the stair core

CAD-ready plan

Walls, doors, windows and columns exported as DXF, so your drawings start from what is actually there.

A measured floor plan with dimensions, half drawn and half shown in 3D from above

Measure anything later

Forgot a sill height or the soffit depth? Measure it in the record, with no trip back.

A coloured LiDAR point cloud of a whole building, roof removed

Spatial files

Point cloud (E57) and 3D model (PLY) exports for your modelling tools.

LiDAR scan · to scale
A handheld laser distance measureIncludedLaser check

Measured by LiDAR, confirmed by laser

The scanner measures every wall, column and soffit directly. And the dimensions that matter are confirmed on site with a laser measure, on every capture.

Plan with your client

Current vs proposed, in the real space.

Test layouts by asking in plain English, then share both versions with your client in one link.

Floor 2 · proposed
10'×12'10'×12'10'×12'KITCHENSTORAGE3 OFFICES84'-2"
FrontView Building IntelligenceFloor 2 · 123 Main Street
Add three 10 × 12 offices along the north wall and keep a 5 ft corridor.
Three offices fit, with 6 ft 4 in left for the corridor. That leaves room for 14 open desks. Want it next to the existing layout?
Ask FrontView Building Intelligence
Before, during and after

Document the whole project on one record.

Request a capture of the existing conditions, another after demolition, and one when the fit-out is done. Each is dated on the same record, and it's yours to share with your client.

  1. 01Every phase, datedCompare existing conditions with the finished space, wall by wall.
  2. 02Share with the whole teamClient, contractor and engineer see the same record, each with what they need.
  3. 03Hand it over when you chooseThe record is yours until you pass it to your client.
Floor 2 · fit-outExample
  1. Capture #1Feb 2025 · existing
  2. Capture #2Mar 2025 · demo done
  3. Capture #3Apr 2025 · fit-out done
What changed since Mar 2025
addedThree private offices along the north wall
addedTen desks in the open office
changedKitchen relocated east

Your next site survey, done in one visit.

Request captures before, during and after the project. Each one is dated on the same record, and it's yours to share with your client.
